Fog lights Installed --- how to aim/level them?

Discussion in 'Gen 3 Prius Accessories and Modifications' started by Eric Henley, Aug 1, 2013.

  1. Eric Henley

    Eric Henley Junior Member

    Joined:
    Jul 22, 2013
    60
    4
    0
    Vehicle:
    2010 Prius
    Model:
    IV
    Just got the local shop to install fog light and they look awesome...

    I was wondering if there's an easy way to aim/level them without taking button bumper cover off? Only one needs to be adjusted the passenger side is slightly brighter and aimed higher than driver side when you view them from a distance...

    Questions:

    1. Does anybody know the bolt size for the leveler on the back?
    2. Any tricks to aim without removing a bunch of bolts and pieces?
    3. What direction goes up vs down... Can't remember if clockwise goes up or counterclockwise goes up?


    Attached Files:

    #1 Eric Henley, Aug 1, 2013
  2. xliderider

    xliderider Senior Member

    Joined:
    Apr 19, 2012
    8,016
    3,198
    0
    Location:
    Honolulu, HI
    Vehicle:
    2011 Prius
    Model:
    Three
    Congrats. You only need to take off three fasteners on the small covers below the foglights. One bolt/screw, and two of those plastic fasteners where you pop the center up with a small flat blade screwdriver before removing.

    If you're looking at the back of the foglight housing, you need to turn the adjustment wheel clockwise to get the aim lower.

    Did they wire up the power wire for your HID harness to the fuse box as well?

    SCH-I535

    #2 xliderider, Aug 1, 2013
  3. Eric Henley

    Eric Henley Junior Member

    Joined:
    Jul 22, 2013
    60
    4
    0
    Vehicle:
    2010 Prius
    Model:
    IV
    So you don't need to remove the black cover underneath the bumper? Just remove that silverish cover of the fog light? Could you expand a little on where those screws are? Would it be easier to remove bottom cover so I could easily access rear of Foglight?

    No sir --- I actually want to see if I can do the relay myself and save the $. I will tackle that one once the relay comes in but want to try to get these fog lights aimed tonight.

    #3 Eric Henley, Aug 2, 2013
  4. xliderider

    xliderider Senior Member

    Joined:
    Apr 19, 2012
    8,016
    3,198
    0
    Location:
    Honolulu, HI
    Vehicle:
    2011 Prius
    Model:
    Three
    I was talking about the small triangular bottom covers just under the foglights.

    DROIDX ? 2

    #4 xliderider, Aug 2, 2013
  5. Eric Henley

    Eric Henley Junior Member

    Joined:
    Jul 22, 2013
    60
    4
    0
    Vehicle:
    2010 Prius
    Model:
    IV
    got it... perfectly leveled now...

    boy were they off by a LOT... thanks again

    #5 Eric Henley, Aug 2, 2013
  6. RRxing

    RRxing Senior Member

    Joined:
    Jul 7, 2009
    2,528
    1,803
    0
    Location:
    NEPA
    Vehicle:
    Other Hybrid
    Model:
    Limited

    From your photo, it appears they installed them upside down. :D

    #6 RRxing, Aug 3, 2013
    milkman44 and xliderider like this.
